Grabador y cortador láser con cinta transportadora Ortur F10 de 10 W, 20 W y 40 W
- Compatibilidad versátil con módulos láser, compatible con módulos láser Ortur de 10 W, 20 W, 40 W y otros
- Gran área de trabajo de 118'' × 15,75'', límites de tamaño de corte
- Los rodillos de presión dobles evitan el desplazamiento del material y garantizan un efecto de grabado preciso.
- Imprescindible para aficionados al bricolaje y pequeñas empresas, perfecto para crear grandes proyectos.
- ‼️ Plazo de entrega estimado: principios de diciembre
Ortur F10 Conveyor Laser Engraver
Feed Large Materials, Engrave with Precision, Switchable Laser Modules to Easily Master Diverse Scenario.
40W Laser Module
ldeal for Thick Cutting Projects and Increase Working Efficiency
Flexible Power Switching of 40W and 20W
One-pass Cutting for 15mm Black Acrylic
One-pass Cutting for 15mm Plywood
20W Laser Module
Suitable for Both Engraving and Cutting Projects
Unleash 380+ Colors on Stainless Steel
One-pass Cutting for 8mm Black Acrylic
One-pass Cutting for 10mm Plywood
10W Laser Module
Best choice for Engraving, Versatile for Light Cutting
Present 256 Kinds of Gray Engraving
One-pass Cutting for 5mm Black Acrylic
One-pass Cutting for 8mm Plywood
More Thoughtful Design
Dual Pressure Rollers for Precise Engraving Effect
Stable and Secure Precision Support Stands
Automatic Pin-point Setting to Prevent Cutting Residues from Falling Out
Retractable Light Connection Plate for Table Protection
Knob for Easy Positioning Adjustment
Aligning Grids for Precise Engraving and Cutting
| Laser Type | 40W Laser Module | 20W Laser Module | 10W Laser Module |
|---|---|---|---|
| Spot Size | 0.1mm*0.15mm | 0.1mm*0.12mm | 0.05mm*0.1mm |
| Cutting Ability | 15mm Black Acrylic, 15mm Plywood | 8mm Black Acrylic, 10mm Plywood | 5mm Black Acrylic, 8mm Plywood |
| Cuttable Materials | Paper、MDF、Plywood、Pine、Paulownia、Cardboard、Corrugated、Dark Acrylic、PVC、Knit、Cotton、ABS Plastics、Felt、Leather、Bamboo、Silica Gel | Paper、MDF、Plywood、Pine、Paulownia、Cardboard、Corrugated、Dark Acrylic、PVC、Knit、Cotton、ABS Plastics、Felt、Leather、Bamboo、Silica Gel | Paper、MDF、Plywood、Pine、Paulownia、Cardboard、Corrugated、Dark Acrylic、PVC、Knit、Cotton、ABS Plastics、Felt、Leather、Bamboo、Silica Gel |
| Engravable Materials | MDF、Plywood、Pine、Paulownia、Paperboard、Paper、Kraft Paper、Leather、Dark Acrylic、Cobblestone、Ceramics、Coated Metal、Plated Metal、Stainless Steel、Glass、Knit、Cotton、ABS Plastics、Bamboo、Silica Gel、Rubber、Ceramic Tile、Marble, Shale, Cement, Brick | MDF、Plywood、Pine、Paulownia、Paperboard、Paper、Kraft Paper、Leather、Dark Acrylic、Cobblestone、Ceramics、Coated Metal、Plated Metal、Stainless Steel、Glass、Knit、Cotton、ABS Plastics、Bamboo、Silica Gel、Rubber、Ceramic Tile、Marble, Shale, Cement, Brick | MDF、Plywood、Pine、Paulownia、Paperboard、Paper、Kraft Paper、Leather、Dark Acrylic、Cobblestone、Ceramics、Coated Metal、Plated Metal、Stainless Steel、Glass、Knit、Cotton、ABS Plastics、Bamboo、Silica Gel、Rubber、Ceramic Tile、Marble, Shale, Cement, Brick |
| Maximum speed | 20,000mm/min | 20,000mm/min | 20,000mm/min |
| Maximum Material Width | 480mm | 480mm | 480mm |
| Minimum Material Width | 65mm | 65mm | 65mm |
| Maximum Material Thickness | 15mm | 15mm | 15mm |
| Working Area | 400*3000mm (118''×15.75'' ) | 400*3000mm (118''×15.75'' ) | 400*3000mm (118''×15.75'' ) |
| Output Voltage | 24V/9A | 24V/6A | 24V/4A |
| Connection Way | USB/Wi-Fi | USB/Wi-Fi | USB/Wi-Fi |
| Wavelength | 445±5nm | 445±5nm | 445±5nm |
Software | Inspiraesth (self-developed App)/Lightburn/LaserGRBL | Inspiraesth (self-developed App)/Lightburn/LaserGRBL | Inspiraesth (self-developed App)/Lightburn/LaserGRBL |
FAQ
Is Ortur F10 compatible with other laser modules?
Yes. All Ortur laser modules are compatible with Ortur F10, e.g. LR4-2B, LU3-40A, LU3-20A, LU2-10A, LU2-4 SF, etc.
What is the maximum thickness of material supported by Ortur F10?
The maximum thickness of material is 15mm.
How do I ensure the material processing accuracy?
It is best to engrave or cut from flat materials that are free of warped edges, arched parts, or twists.
How to clean and maintain Ortur F10?
You can use a brush to clean some parts, such as the dule pressure rollers or the light connection plate. It is recommended to clean Ortur F10 by using tissues moistened with alcohol after using every time. If left uncleaned for a long time, the residual stains may become difficult to clean.
