 | OLM3 | OLM3 LE | OLM2 Pro S2 | OLM2 S2 | AL1 | AL2 |
---|---|---|---|---|---|---|
Main Features | Latest laser engraving machines with smart APP
âSuperior engraving speed âEquipped with Ortur Smart App âBest 8 safety protection including safety lock & emergency button | Cost-effective engraving machine with high performance
âSolid frame & minimalist appearance âEquipped with Ortur Smart App â6 safety protection | The most classic ortur engraving machine
âMetal frame with its own scale âExtended engraving range â7 safety protection including flame detector and emergency button | The most affordable ortur engraver
âMetal frame with its own scale âpleasantly priced â5 safety protection | Semi-cantilever engraving machine
âPre-assembled âBeginner friendly â5 safety protection | High-speed & good-price engraver
âFrame with integral scales âLow center of gravity, more stable â5 safety protection |
 |  |  |  |  |  |  |
Maximum Speed | 20,000mm/min | 15,000mm/min | 15,000mm/min | 5,000mm/min | 5,000mm/min | 15,000mm/min |
Working Area | 400mm*400mm | 400mm*400mm | 400mm*400mm | 390mm*410mm | 180mm*180mm | 390mm*390mm |
Extended Area | 400mm*850mm | Â | 400mm*800mm | Â | Â | 390mm*600mm |
Product Size | 658mm*625mm*150mm | 614mm*588mm*128mm | 600mm*570mm*130mm | 580mm*550mm*150mm | 450mm*320mm*140mm | 588mm*580mm*150mm |
Package Size | 660mm*230mm*230mm | 670mm*330mm*130mm | 660mm*250mm*110mm | 620mm*215mm*130mm | 480mm*380mm*170mm | 630mm*290mm*110mm |
Supported Software | LightBurnăLaserGRBLăLaser Explorer | LightBurnăLaserGRBLăLaser Explorer | LightBurnăLaserGRBL | LightBurnăLaserGRBL | LightBurnăLaserGRBL | LightBurnăLaserGRBL |
Supported Functions | WIFI/APP/USB/TF Card | WIFI/APP/USB/TF Card | USB | USB | USB | USB |
Supported Formats | JPG, SVG, PNG, BMP, G-code, CAD, AI,CDR, DWG | JPG, SVG, PNG, BMP, G-code, CAD, AI,CDR, DWG | JPG, SVG, PNG, BMP, G-code, CAD, AI,CDR, DWG | JPG, SVG, PNG, BMP, G-code, CAD, AI,CDR, DWG | JPG, SVG, PNG, BMP, G-code, CAD, AI,CDR, DWG | JPG, SVG, PNG, BMP, G-code, CAD, AI,CDR, DWG |
Supported Systems | Android & iOS & Windows & Mac OS & Linux | Android & iOS & Windows & Mac OS & Linux | Windows & Mac OS & Linux | Windows & Mac OS & Linux | Windows & Mac OS & Linux | Windows & Mac OS & Linux |
Safety Protections | · Safety Lock
· Emergency Stop Button · Laser Exposure Time Limit · Tilt Motion Detection · USB Connection Monitor · Active Position Protection · Anti-crash Watchdog Mechanism · Voltage & Current Safety Control System | · Laser Exposure Time Limit
· Tilt Motion Detection · USB Connection Monitor · Active Position Protection · Anti-crash Watchdog Mechanism · Voltage & Current Safety Control System | · Flame Detector
· Emergency Stop Button · Tilt Motion Detection · Laser Exposure Time Limit · USB Connection Monitor · Active Position Protection · Voltage & Current Safety Control System | · Tilt Motion Detection
· USB Connection Monitor · Laser Exposure Time Limit · Active Position Protection · Voltage & Current Safety Control System | · Tilt Motion Detection
· USB Connection Monitor · Laser Exposure Time Limit · Active Position Protection · Voltage & Current Safety Control System | · Tilt Motion Detection
· USB Connection Monitor · Laser Exposure Time Limit · Active Position Protection · Voltage & Current Safety Control System |
 | Buy Now > | Buy Now > | Buy Now > | Buy Now > | Buy Now > | Buy Now > |
 | OLM3 | OLM3 LE | OLM2 Pro S2 | OLM2 S2 | AL1 | AL2 |
---|---|---|---|---|---|---|
Maximum Speed | 20,000mm/min | 15,000mm/min | 15,000mm/min | 5,000mm/min | 5,000mm/min | 15,000mm/min |
Working Area | 400mm*400mm | 400mm*400mm | 400mm*400mm | 390mm*410mm | 180mm*180mm | 390mm*390mm |
Extended Area | 400mm*850mm | Â | 400mm*800mm | Â | Â | 390mm*600mm |
Product Size | 658mm*625mm*150mm | 614mm*588mm*128mm | 600mm*570mm*130mm | 580mm*550mm*150mm | 450mm*320mm*140mm | 588mm*580mm*150mm |
Package Size | 660mm*230mm*230mm | 670mm*330mm*130mm | 660mm*250mm*110mm | 620mm*215mm*130mm | 480mm*380mm*170mm | 630mm*290mm*110mm |
Supported Software | LightBurnăLaserGRBLăLaser Explorer | LightBurnăLaserGRBLăLaser Explorer | LightBurnăLaserGRBL | LightBurnăLaserGRBL | LightBurnăLaserGRBL | LightBurnăLaserGRBL |
Supported Functions | WIFI/APP/USB/TF Card | WIFI/APP/USB/TF Card | USB | USB | USB | USB |
Supported Formats | JPG, SVG, PNG, BMP, G-code, CAD, AI,CDR, DWG | JPG, SVG, PNG, BMP, G-code, CAD, AI,CDR, DWG | JPG, SVG, PNG, BMP, G-code, CAD, AI,CDR, DWG | JPG, SVG, PNG, BMP, G-code, CAD, AI,CDR, DWG | JPG, SVG, PNG, BMP, G-code, CAD, AI,CDR, DWG | JPG, SVG, PNG, BMP, G-code, CAD, AI,CDR, DWG |
Supported Systems | Android & iOS & Windows & Mac OS & Linux | Android & iOS & Windows & Mac OS & Linux | Windows & Mac OS & Linux | Windows & Mac OS & Linux | Windows & Mac OS & Linux | Windows & Mac OS & Linux |
Safety Protections | · Safety Lock · Emergency Stop Button · Laser Exposure Time Limit · Tilt Motion Detection · USB Connection Monitor · Active Position Protection · Anti-crash Watchdog Mechanism · Voltage & Current Safety Control System | · Laser Exposure Time Limit · Tilt Motion Detection · USB Connection Monitor · Active Position Protection · Anti-crash Watchdog Mechanism · Voltage & Current Safety Control System | · Flame Detector · Emergency Stop Button · Tilt Motion Detection · Laser Exposure Time Limit · USB Connection Monitor · Active Position Protection · Voltage & Current Safety Control System | · Tilt Motion Detection · USB Connection Monitor · Laser Exposure Time Limit · Active Position Protection · Voltage & Current Safety Control System | · Tilt Motion Detection · USB Connection Monitor · Laser Exposure Time Limit · Active Position Protection · Voltage & Current Safety Control System | · Tilt Motion Detection · USB Connection Monitor · Laser Exposure Time Limit · Active Position Protection · Voltage & Current Safety Control System |
Main Material | Aluminum + Fireproof ABS | Aluminum + Fireproof ABS | Aluminum + SPCC | Aluminum + Acrylic | Aluminum + Acrylic | Aluminum + SPCC |
Main Features | Latest laser engraving machines with smart APP âSuperior engraving speed âEquipped with Ortur Smart App âBest 8 safety protection including safety lock & emergency button | Cost-effective engraving machine with high performance âSolid frame & minimalist appearance âEquipped with Ortur Smart App â6 safety protection | The most classic ortur engraving machine âMetal frame with its own scale âExtended engraving range â7 safety protection including flame detector and emergency button | The most affordable ortur engraver âMetal frame with its own scale âpleasantly priced â5 safety protection | Semi-cantilever engraving machine âPre-assembled âBeginner friendly â5 safety protection | High-speed & good-price engraver âFrame with integral scales âLow center of gravity, more stable â5 safety protection |
Laser Modules | LU3-20A | LU2-10A | LU2-4 SF | LI2-4 LF | LU2-2 |
---|---|---|---|---|---|
Optical Power | 20W | 10W | 5.5W | 5.5W | 1.6W |
Adapter Power Input | 24V / 6A | 24V / 4A | 24V / 2A | 24V / 2A | 24V / 2A |
Wavelength | 450±5nm | 450±5nm | 450±5nm | 450±5nm | 450±5nm |
Spot Size | 0.08mm*0.08mm | 0.05mm*0.1mm | 0.12mm*0.15mm | 0.17mm*0.25mm | 0.07mm*0.06mm |
Engraving Precision | 0.01mm | 0.01mm | 0.01mm | 0.01mm | 0.01mm |
Focusing Mode | Manual | Manual | Manual | Manual | Manual |
Focal Length | 56.5mm | 50mm | 30mm | 50mm | 50mm |
Spot Technology | Spatial Compression | Optical Compression | Optical Compression | Optical Compression | Â |
Weight | 500g | 235g | 196g | 196g | 143.6g |
Lifetime | >10,000H | >10,000H | >10,000H | >10,000H | >10,000H |
Air Pump Adaptability | â (with free air pump) | â | Â | â | Â |
Z-Height Adjuster Adaptability | Require extra limitblock > | â | â | â | â |
Window Mirror Replacement | â | â | Â | Â | Â |
Engraving | MDFăPlywoodăPineăPaulowniaăPaperboardăPaperăKraft PaperăLeatherăDark AcrylicăCobblestoneăCeramicsăCoated MetalăPlated MetalăStainless SteelăGlassăKnităCottonăABS PlasticsăBambooăSilica GelăRubberăCeramic TileăMarble, Shale, Cement, Brick | MDFăPlywoodăPineăPaulowniaăPaperboardăPaperăKraft PaperăLeatherăDark AcrylicăCobblestoneăCeramicsăCoated MetalăPlated MetalăStainless SteelăGlassăKnităCottonăABS PlasticsăBambooăSilica GelăRubberăCeramic TileăMarble, Shale, Cement, Brick | MDFăPlywoodăPineăPaulowniaăPaperboardăPaperăKraft PaperăLeatherăDark AcrylicăCobblestoneăCeramicsăCoated MetalăPlated MetalăStainless SteelăGlassăKnităCottonăABS PlasticsăBambooăSilica GelăRubberăCeramic Tile | MDFăPlywoodăPineăPaulowniaăPaperboardăPaperăKraft PaperăLeatherăDark AcrylicăCobblestoneăCeramicsăCoated MetalăPlated MetalăStainless SteelăGlassăKnităCottonăABS PlasticsăBambooăSilica GelăRubberăCeramic Tile | MDFăPlywoodăPineăPaulowniaăPaperboardăPaperăKraft PaperăLeatherăDark AcrylicăCobblestoneăCeramicsăCoated MetalăPlated MetalăGlassăKnităCottonăABS PlasticsăBambooăSilica GelăRubberăCeramic Tile |
Cutting | PaperăMDFăPlywoodăPineăPaulowniaăCardboardăCorrugatedăDark AcrylicăPVCăKnităCottonăABS PlasticsăFeltăLeatherăBambooăSilica Gel | PaperăMDFăPlywoodăPineăPaulowniaăCardboardăCorrugatedăDark AcrylicăPVCăKnităCottonăABS PlasticsăFeltăLeatherăBambooăSilica Gel | PaperăMDFăPlywoodăPineăPaulowniaăCardboardăCorrugatedăDark AcrylicăPVCăKnităCottonăABS Plastics | PaperăMDFăPlywoodăPineăPaulowniaăCardboardăCorrugatedăDark AcrylicăPVCăKnităCottonăABS Plastics | PaperăMDFăPlywoodăPineăPaulowniaăCardboardăCorrugatedăDark AcrylicăPVCăKnităCottonăABS Plastics |
Directly Adaptable Machines | OLM3 20W (Requires OUC with other engravers) | OLM3ăOLM3 LEăOLM2 Pro S2 | OLM3ăOLM3 LEăOLM2 Pro S2ăOLM2 S2ăAL1ăAL2 | OLM3ăOLM3 LEăOLM2 Pro S2ăOLM2 S2ăAL1ăAL2 | OLM3ăOLM3 LEăOLM2 Pro S2ăOLM2 S2ăAL1ăAL2 |
 | Buy Now > | Buy Now > | Buy Now > | Buy Now > |  |
* With OUC1.0, you can realize flexible compatibility between Ortur machines & modules and even other brands.
Strong airflow minimizes debris and burn marks, working with LEP1.0 for smooth exhaust and OSP1.0 for a clean carving environment.
Raise machine for diversified engraving. Necessary partner for Y series rollers, only available for the Ortur Laser Master 3.
Raise machine for diversified engraving. Necessary partner for Y series rollers, suitable for all laser engraving machines.
Rotary cylinder with 7 gears, suitable for engraving cylindrical objects, which should be raised for use.
Pre-assembled rotating cylinder for better adaptation to long objects, which should be raised for use.
Installation-free, multi-mode rotary chuck for objects as large as spheres and as small as rings, needing to be raised for use.
Protects desktop from damage, helps dissipate heat and exhaust fumes, 82% of users buy it with an OAP1.0.
Enclosed metal shell blocks smoke and protects eyes, creating a perfect smokeless environment with OSP1.0, only for laser master 2 pro.
Enclosed 2.0 for all engraving machines, flame and dust proof, compatible with ortur APP , suitable for Y series drums and OSP1.0.
Easier to adjust the focus of the laser module to engrave thicker objects.
Three-layer filtration, large airflow, purifies gas and removes dust.
Extend the engraving range of OLM3 from 400*400mm to 400*850mm, providing a larger creation possibilities and compatible with FFT1.0 or OUR1.0.
Extend the engraving range of OLM2 pro from 400*400mm to 400*800mm, providing a larger creation possibilities and compatible with OUR1.0.
Extend the engraving range of AL2 from 390*390mm to 3390*600mm, providing a larger creation possibilities and compatible with OUR1.0.
Advanced laser goggles, specialized in filtering 180-530 nm lasers, large and wrap-around frame.
Replaceable window mirror set, protecting internal mirrors from dirt.
